Specifications
Display
Display Type 24" HDTV TFT LCD(Backlight LED)
Resolution 1920x1080 (WSUGA)
Max.color 16.7M
Luminance 300 cd/m2
View Angle 89掳(H) , 89掳(V)
Contrast Ratio 5000:1
Response Time 8 ms
Backlight Life 50,000hrs
Input Signals
RGB Signal D-SUB 15P Connector (female)
DC input 2-Pin Terminal Block
HDMI Signal HDMI connector (female)
Touch screen RS232 (option) D-SUB 9p connector (female)
Touch screen USB (option) USB-A type connector (female)
Available Options
Touch screen Resistive type touch screen with USB controller
DC Power Input Wide Range 9~36v DC input
Power supply
Standard 100~240VAC,50/60Hz, DC12V@ 5A / 60W ,external ac adapter
DC-DC Power DC 9 ~ 36v input power module(optional)
Environmental
Construction Heavy duty steel and aluminum front panel
Operate temperature 0 掳C to 50 掳C
Storage temperature -20 掳C to 60 掳C
Storage humidity 10% to 90% non-condensing
Anti-Vibration 17HZ-500 HZ 1G PTP
Anti-Shock 1G / peak( 11m sec)
Packing info
Dimensions (WxHxD) 581 x 380 x 47 mm
Weight Net: 16.5kg , Gross:20 kg
24 inch touch screen monitor, 1920x1080 touch panel monitor, 24 inch industrial monitor
Tags: Wide screen industrtial monitor, Resistive Touch Screen, 24" wide lcd, 1920x1080 Full HD
